Specs

Specifications

Details H1316TB H1316FB H1316MB H1316DB H1316SB
Exterior Length 15'11" 15'11" 15'11" 15'11" 15'11"
Exterior Height 1 9'11" 9'11" 9'11" 9'11" 9'11"
Exterior Width 2 8'1" 8'1" 8'1" 8'1" 8'1"
Awning Length 10' 10' 10' 10' 10'
Interior Height 6'5" 6'5" 6'5" 6'5" 6'5"
Freshwater Tank Capacity (gal.) 4 31 31 31 31 31
Water Heater Capacity (gal.) 6 6 6 6 6
Holding Tank Capacity — Black (gal.) 4 4.75 4.75 4.75 4.75 4.75
Holding Tank Capacity — Gray (gal.) 4 25 25 25 25 25
LP Capacity (lbs.) 5 20 20 20 20 20
GVWR (lbs.) 4,200 4,200 4,200 4,200 4,200
Sleeps 8 4 3 2 3 4
Axles (lbs.) 1 @ 4,000 1 @ 4,000 1 @ 4,000 1 @ 4,000 1 @ 4,000
Dry Weight (lbs.) 3,122 3,178 3,156 3,170 3,284
Furnace (BTU) 18,000 18,000 18,000 18,000 18,000
Dry Hitch Weight (lbs.) 576 546 566 536 462
Hitch Height 28" 28" 28" 28" 28"
Tire Size 225/75R16E 225/75R16E 225/75R16E 225/75R16E 225/75R16E
head
body
Interior

Molle panel (Not applicable on 1316MB)
Flip down table (Only applicable on 1316SB)
TransCore fully composite flooring
JBL portable Bluetooth speaker
Interior TV prep
Folding table (Only applicable on 1316TB, 1316SB, and 1316MB)
Designated wardrobe

Galley

1.1 cubic ft. convection microwave
3.3 cubic ft. 12-volt refrigerator
Undermount single bowl stainless steel sink with cover
Portable induction cooktop
Pull out countertop extension
Contemporary cabinet style

Bath

Wet bath with power vent
Integrated gear drying racks
Cassette Toilet
Cubby for dry storage

Bedroom

Versatile sleeping arrangements
Sleeps up to 4 adults depending on the floorplan

Exterior

NXG engineered frame
2" thick FILON® MAX fiberglass sidewalls with
Azdel Onboard® composite panels
Fully walkable roof
Side-mount ladder
Weather proof junction box
Premium Suspension Upgrade: BAL Independent Suspension with Dexter TorFlex torsion stub axles
Goodyear Wrangler 16" off-road tires
Aluminum wheel assemblies
Goodyear Wrangler 16" spare tire
Powered patio awning with LED lighting
Rear dual door opening 60" x 60" with screens (Only applicable on 1316SB)
Manual rear and off-camp side batwing awning with drop-down panels for exterior shower
Designated outdoor shower
Power tongue jack
Power stabilization jacks
All LED exterior lighting with reverse lights integrated into brake lights
Fully enclosed underbelly with radiant foil insulation
Powder coated roof exoskeleton
Powder coated fender gear boxes
2" accessory receiver hitch with 350 lbs. capacity
Lower nerf bars integrated into the frame
Exterior patio side LP quick connect
Thick core slam latch baggage doors
Outdoor kitchen (Only applicable on 1316FB and 1316DB)
Portable Truma® cooler (Only applicable on 1316FB and 1316DB)
Protective metal front and side brush guard
Quick connect spray port
Camp side TV prep
Furrion side-mount camera prep
Furrion back-up camera prep

Heating & Cooling System

6-gallon gas/electric/DSI water heater
18,000 BTU LP furnace
13,500 low-profile roof A/C
CSA vents
20lb. LP tank

Electrical System

200-watt solar panel with 30-amp charge controller and resettable breaker
Side-mount solar prep for additional panel
Inverter prep
Winnebago all-in-one control panel
12-volt tank pad heaters with interior switch
USB/ USBC charge ports
WiFi Prep integrated into King® Omni Antenna
Wireless cellphone charger
Tire Pressure Monitoring System prep


Plumbing System

6-gallon gas/electric/DSI water heater
31-gallon freshwater tank
4.75-gallon cassette toilet
25-gallon gray tank

Warranty

See your dealer for complete warranty information.

Packages

MSRP Disclaimer

MSRP shown in USD. Pricing does not include freight, taxes, title, license, dealer prep charges, or other miscellaneous fees. Due to our commitment to continuous product improvement, Winnebago reserves the right to change components, standard features, options, specifications, materials, and pricing without notice and at any time. Please contact your local dealer to review current product details and pricing.
