Spyder

It’s time for all your toys to meet your next favorite fifth wheel. The unparalleled storage of the feature-packed Spyder Fifth Wheel means that wherever you adventure, more of your gear gets to come along for the ride.

Starting At: $58,237
Spyder

Floorplans

34'10ʺ Length
7 Sleeps9
42' Length
8 Sleeps9
42' Length
8 Sleeps9

Features

W Series Foundation

W Series Foundation

With the W Series Foundation, each of the four available floorplans are built right from the same source, guaranteeing a single point of service to simplify your life.

Secure Space

Secure Space

Strap in and buckle up. With a massive 13-14 ft. of garage space, your toys will have plenty of elbow room. And with dependable frame-bolted D-rings, your gear stays exactly where you want.

Zero Gravity Ramp

Zero Gravity Ramp

The industry-leading Zero Gravity cargo ramp offers zero resistance, zero sweat loading and unloading your gear.

Winnebago Spyder Fifth Wheel full kitchen view, featuring appliances and storage

Well-Appointed Kitchen

Fuel up in the Spyder Fifth Wheel’s fully loaded kitchen area, featuring top-notch appliances, including recessed 3 burner range w/oven, large sink w/ sink covers and 8 Cu. ft. refrigerator.

Power Player

Power Player

Play on and off the grid with the Spyder Fifth Wheel’s on-board generator, 100-gallon freshwater capacity and a 30-gallon fuel tank.

Specifications

S29SFWNew S36GWSNew S37BGSNew
Exterior Length 34'10ʺ 42' 42'
Exterior Height1 13'5" 13'5" 13'5"
Exterior Width2 8'6" 8'6" 8'6"
Exterior Storage3 (cu. ft.) --- --- ---
Awning Length 20' 20' 20'
Interior Height 8'6" 8'6" 8'6"
Interior Width --- --- ---
Freshwater Tank Capacity4 (gal.) 100 100 100
Water Heater Capacity (gal.) 10 10 10
Holding Tank Capacity4 — Black (gal.) 50 100 100
Holding Tank Capacity4 — Gray (gal.) 50 50 50
LP Capacity5 (lbs.) 60 60 60
Fuel Capacity (gal.) --- --- ---
GCWR6 (lbs.) --- --- ---
GVWR (lbs.) 16,000 16,000 16,000
GAWR - Front (lbs.) --- --- ---
GAWR - Rear (lbs.) --- --- ---
Wheelbase --- --- ---
Cassette Toilet Capacity4 (gal.) --- --- ---
Sleeps9 7 8 8
Axles (lbs.) [email protected],000 2 @ 7,000 2 @ 7,000
Dry Weight (lbs.) 11,420 13,268 TBD
Furnace (BTU) 30,000 30,000 30,000
Garage Length 14.9' 13' 13'
Hitch Weight (lbs.) 3,000 3,590 TBD
Slideouts --- --- ---
Tire Size 235/80R16G 235/80R16G 235/80R16G

LED interior lighting
Cable TV & satellite prep
Cold crack resistant floor
Night shades
LED TV
Power vent fan
Beaver tail rear end
2,500 lb. tie downs
TV antenna w/ Wifi prep
LED TV
USB charge ports
DVD/CD/AM/FM/Dual Zone Ent. w/ HDMI and Bluetooth

Residential panel cabinet doors & drawers
30" convection microwave
10.3 cu. ft. 12V refrigerator w/ pantry
Single bowl stainless steel kitchen sink w/ residential style faucet
Recessed 3 burner cooktop w/ backlit knobs, glass cover & oven
Full extension metal drawer guides

Optional Equipment:

12 cubic foot refrigerator

Large shower skylight
Porcelain toilet

60" x 80" Queen bed

Optional Equipment:

32" LED TV in bedroom
King bed

Aluminum frame rear ramp door
Exterior high mount loading lights
Solid quad entry steps (main)
Wide body construction
Gel coat fiberglass front cap w/ integrated LED lighting
Aluminum framed & laminated sidewalls
Tinted safety glass windows
Aluminum rims
Spare tire
Manual rear stabilizers
Universal docking station w/ black tank flush
LED exterior lights
Exterior speakers
Rear view camera prep
Power awning w/ LED lighting
Roof mount solar charger prep
30 gal fuel station w/ gen prep
MorRyde Zero-G rear ramp door
Leaf spring suspension
HD axles w/ brakes
30" x 72" radius entry door w/ window (main entry)
Roof ladder (side mount)
Exterior fiberglass sidewalls w/ Azdel
Walk-on roof decking
One piece TPO roof membrane
Large fold away entry grab handle
Exterior shower

Optional Equipment:

Rear ramp patio system with folding rails
Rear ramp patio screen (N/A w/ 3-season garage wall)
Power HappiJac bed with convertible sofa
Rota-Flex pin box
Electric 6-Point Level Up (Mandatory all models)
3-Season Garage Wall (N/A w/ rear ramp patio screen)

15K BTU A/C
True Trax A/C ducting system
30,000 BTU furnace
In-wall heat ducts
Heated and enclosed underbelly w/ Thermo Foil insulation
Radiant Foil roof and front cap insulation

Optional Equipment:

2nd 13.5K BTU air conditioner
12 V heat pads

55 Amp/ 12V Converter
Power cord w/ LED light
Battery disconnect switch
Electric 6 point Level Up (mandatory option)
50 Amp service w/ 2nd A/C prep

Optional Equipment:

Onan 5500 Gen
(2) 100-Watt solar panels

10 gal DSI gas/electric water heater w/ bypass
Winterization valve
Exterior LP Quick Connect
Dual 30# LP tanks
Large 1 1/2" fresh water tank drain valve

  1. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.  The actual height of our vehicle may vary by several inches depending on chassis or equipment variations.  Please contact your dealer for further information.
  2. Not applicable to this model
  3. Not applicable to this model
  4. Capacities are based on measurements prior to tank installation.  Slight capacity variations can result due to installation applications.
  5. Not applicable on this model
  6. Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR and GCWR, as well as adequate trailer brakes.  Please refer to the Operator’s Manual of your vehicle for further towing information.
  7. Not applicable to this model
  8. See your dealer for complete warranty information.
  9. Sleeping capacity is the maximum based on a specific floorplan.

Because features, specification, equipment, and options may vary from those highlighted on this website, the buyer is responsible for confirming with the dealer the features, specifications, equipment, and options included in their specific vehicle.

In addition, Winnebago’s program of continuous product improvement may result in changes to vehicle specifications, equipment, model availability, and price without notice.

**Base Manufacturers Suggested Retail Price shown. Base price does not include tax, title, license, delivery charges or optional features. Prices are subject to change without notice.
